| Číslo dielu | KCG089HV1AA-G00 |
| Značka | Kyocera |
| Veľkosť | 8.9 |
| Aplikácia | IA |
| Rozhodnutie | 640×240 |
| Zloženie | LCM |
| Jas | 150 |
| CR | 30:1 |
| Farby | Color |
| Podsvietenie | CCFL |
| Rozhranie | Parallel Data |
| značka panelu | Kyocera |
| panelový model | KCG089HV1AA-G00 |
| typ panelu | CSTN-LCD , LCM |
| veľkosť panelu | 8.9 inch |
| rozhodnutie | 640(RGB)×240 , HVGA |
| režim zobrazenia | STN, Normally Black, Transmissive |
| aktívna oblasť | 211.18×79.18 mm |
| obrys | 246×103×12.2 mm |
| povrch | Glare (Haze 0%) |
| jas | 150 cd/m² (Typ.) |
| kontrastný pomer | 30:1 (Typ.) |
| zobraziť farby | Color |
| Doba odozvy | 190/180 (Typ.)(Tr/Td) |
| pozorovací uhol | 50/50/35/20 (Typ.)(CR≥2)(L/R/U/D) |
| frekvencia | 75Hz |
| typ lampy | 1 pcsCCFLOptional |
| signálové rozhranie | Parallel Data (8-bit), 20 pins |
| vstupné napätie | 3.3/5.0V (Typ.)(VDD) |
| aplikácie | IA |
