| Číslo dielu | EK08009-70235 |
| Značka | Other |
| Veľkosť | 8.0 |
| Aplikácia | DPF |
| Rozhodnutie | 800×600 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 500:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | No Brand |
| panelový model | EK08009-70235 4 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 8.0 inch |
| rozhodnutie | 800(RGB)×600 , SVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 162×121.5 mm |
| obrys | 183×141 mm |
| povrch | Antiglare |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 10/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S11PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit), 50 pins |
| vstupné napätie | 3.3/10.4V (Typ.)(VCC/AVDD) |
| rohs: | |
| aplikácie | DPF |
