| Číslo dielu | C070VW02 V1 |
| Značka | AUO |
| Veľkosť | 7.0 |
| Aplikácia | CNS |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 300:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | AUO |
| panelový model | C070VW02 V1 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 152.4×91.44 mm |
| obrys | 170.8×107.95×21.5 mm |
| povrch | Antiglare (Haze 40%), Hard coating (3H) |
| jas | 350 cd/m² (Min.) |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 20/30 (Max.)(Tr/Td) |
| pozorovací uhol | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 4S4PWLEDWithout Driver |
| signálové rozhranie | TTL (1 ch, 6-bit), 98 pins |
| vstupné napätie | 3.3/9.8/15/-7V (Typ.)(VDD/AVDD/VGH/VGL) |
| rohs: | |
| aplikácie | CNS |
