| Číslo dielu | C043GW01 V0 |
| Značka | AUO |
| Veľkosť | 4.3 |
| Aplikácia | CNS |
| Rozhodnutie | 400×234 |
| Zloženie | LCM |
| Jas | 600 |
| CR | 400:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | AUO |
| panelový model | C043GW01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 4.3 inch |
| rozhodnutie | 400(RGB)×234 |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 94.8×52.65 mm |
| obrys | 107.7×65.6 mm |
| povrch | |
| jas | 600 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Min.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 15/20 (Typ.)(Tr/Td) |
| pozorovací uhol | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLED |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.)(VDD) |
| aplikácie | CNS |
