| Číslo dielu | B116XAT03.1 |
| Značka | AUO |
| Veľkosť | 11.6 |
| Aplikácia | PAD |
| Rozhodnutie | 1366×768 |
| Zloženie | Assembly |
| Jas | 350 |
| CR | 800:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | B116XAT03.1 |
| typ panelu | a-Si TFT-LCD , Assembly |
| veľkosť panelu | 11.6 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| aktívna oblasť | 256.125×144 mm |
| obrys | 288.8×176.8×8.43 mm |
| povrch | Hard coating (8H) |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | LVDS (1 ch, 8-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | PAD |
