| Číslo dielu | ASI545FB01-0 |
| Značka | Samsung |
| Veľkosť | 55 |
| Aplikácia | DID |
| Rozhodnutie | 1920×1080 |
| Zloženie | OLED |
| Jas | 500 |
| CR | |
| Farby | 1.07B |
| Podsvietenie | self |
| Rozhranie | LVDS |
| značka panelu | SAMSUNG |
| panelový model | ASI545FB01-0 |
| typ panelu | TOLED , OLED |
| veľkosť panelu | 55 inch |
| rozhodnutie | 1920×1080(RGB) , FHD |
| aktívna oblasť | 1209.6×680.4 mm |
| obrys | 1219.4×697 mm, Videowall Seam 9.8 mm |
| povrch | Hard coating (2H), Antireflection |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | |
| zobraziť farby | 1.07B (10-bit), CIE1931100% |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | LVDS (2 ch, 10-bit), 51 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | DID |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| HV550WUP-200 | BOE | 55 | 1920×1080 |
| LC550EUB-SCA1 | LG Display | 55 | 1920×1080 |
| LC550EUD-SCA1 | LG Display | 55 | 1920×1080 |
| LC550EUG-PEF1 | LG Display | 55 | 1920×1080 |
| LTA550HJ05 | Samsung | 55 | 1920×1080 |
| LTI550HN03 | Samsung | 55 | 1920×1080 |
| T546HW02 V1 | AUO | 55 | 1920×1080 |
| T550QVD01.0 | AUO | 55 | 3840×2160 |
| V546H1-LS1 | Innolux | 55 | 1920×1080 |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| LD470DXS-SCA1 | LG Display | 47 | 1366×768 |
| LD470DXS-SCB1 | LG Display | 47 | 1366×768 |
| LD550DUN-THB3 | LG Display | 55 | 1920×1080 |
| LTI460HN01 | Samsung | 46 | 1920×1080 |
| LTI460HN07 | Samsung | 46 | 1920×1080 |
| LTI460HN09 | Samsung | 46 | 1920×1080 |
| LTI460HN10 | Samsung | 46 | 1920×1080 |
| LTI460HN11 | Samsung | 46 | 1920×1080 |
| LTI550HN14 | Samsung | 55 | 1920×1080 |
