| Číslo dielu | LD470DXS-SCB1 |
| Značka | LG Display |
| Veľkosť | 47 |
| Aplikácia | DID |
| Rozhodnutie | 1366×768 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 1400:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | LG Display |
| panelový model | LD470DXS-SCB1 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 47 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| režim zobrazenia | S-IPS, Normally Black, Transmissive |
| aktívna oblasť | 1039.87×584.64 mm |
| obrys | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| povrch | Antiglare (Haze 10%), Hard coating (3H) |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 1400:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | 12 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 8-bit), 30 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | DID |
