| Číslo dielu | AMCB004 |
| Značka | Samsung |
| Veľkosť | 2.4 |
| Aplikácia | MPH |
| Rozhodnutie | 240×320 |
| Zloženie | OLED |
| Jas | 200 |
| CR | 30000:1 |
| Farby | 262K |
| Podsvietenie | self |
| Rozhranie | CPU |
| značka panelu | SAMSUNG SDI |
| panelový model | AMCB004 |
| typ panelu | AM-OLED , OLED |
| veľkosť panelu | 2.4 inch |
| rozhodnutie | 240(RGB)×320 , QVGA |
| aktívna oblasť | 36.72×48.96 mm |
| obrys | 42.32×58.42 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 30000 : 1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE1931106% |
| pozorovací uhol | 90/90/90/90 (Max.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | CPU, 31 pins |
| vstupné napätie | 3.0/3.8V (Typ.)(VDD/Vbat) |
| aplikácie | MPH |
