| Číslo dielu | ACX565AKM-7 |
| Značka | SONY |
| Veľkosť | 3.5 |
| Aplikácia | MPH |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 275 |
| CR | 500:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | CDP |
| značka panelu | SONY |
| panelový model | ACX565AKM-7 |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | VSPEC II, Normally Black, Transflective |
| aktívna oblasť | 76.8×46.08 mm |
| obrys | 87.9×52.18 mm |
| povrch | |
| jas | 275 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.)(Transmissive)24:1 (Typ.)(Reflective) |
| zobraziť farby | 16.7M (8-bit), CIE193170% |
| Doba odozvy | 12/7 (Typ.)(Tr/Td) |
| pozorovací uhol | |
| frekvencia | 60Hz |
| typ lampy | 3S2PWLEDWithout Driver |
| signálové rozhranie | CDP (2 Lane) + SPI, 24 pins |
| vstupné napätie | 1.8/2.75V (Typ.)(VDDI/VDD) |
| aplikácie | MPH |
