| Číslo dielu | LTM030DH60 |
| Značka | TOSHIBA |
| Veľkosť | 3.0 |
| Aplikácia | MPH |
| Rozhodnutie | 240×427 |
| Zloženie | CELL |
| Jas | 0 |
| CR | 800:1 |
| Farby | 262K |
| Podsvietenie | No B/L |
| Rozhranie | M-CMADS |
| značka panelu | TOSHIBA |
| panelový model | LTM030DH60 |
| typ panelu | LTPS TFT-LCD , CELL |
| veľkosť panelu | 3.0 inch |
| rozhodnutie | 240(RGB)×427 |
| režim zobrazenia | TN, Normally White, Transflective |
| aktívna oblasť | 36.72×65.33 mm |
| obrys | 40.52×72.63 mm |
| povrch | |
| hĺbka skla | 0.10+0.20 mm |
| priepustnosť | 5.4% (Typ.)(with Polarizer) |
| kontrastný pomer | 800:1 (Typ.)(Transmissive)4:1 (Typ.)(Reflective) |
| zobraziť farby | 262K , CIE193164% |
| Doba odozvy | 45/45 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/70/70 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| signálové rozhranie | M-CMADS + SPI, 22 pins |
| vstupné napätie | 2.8/1.8V (Typ.)(VCC/VDDIO) |
| aplikácie | MPH |
