| Číslo dielu | A027DN03 V1 |
| Značka | AUO |
| Veľkosť | 2.7 |
| Aplikácia | DSC |
| Rozhodnutie | 320×240 |
| Zloženie | LCM |
| Jas | 350 |
| CR | 300:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | Serial RGB |
| značka panelu | AUO |
| panelový model | A027DN03 V1 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 2.7 inch |
| rozhodnutie | 320(RGB)×240 , QVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 54×40.5 mm |
| obrys | 63.5×46.6×2.4 mm |
| povrch | Glare (Haze 0%) |
| jas | 350 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 10/25 (Typ.)(Tr/Td) |
| pozorovací uhol | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 2S1PWLEDWithout Driver |
| signálové rozhranie | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| vstupné napätie | 3.3/13/-10V (VDD/VGH/VGL) |
| aplikácie | DSC |
