| Číslo dielu | A025DL02 V5 |
| Značka | AUO |
| Veľkosť | 2.5 |
| Aplikácia | DSC |
| Rozhodnutie | 320×240 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 300:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | Serial RGB |
| značka panelu | AUO |
| panelový model | A025DL02 V5 |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 2.5 inch |
| rozhodnutie | 320(RGB)×240 , QVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 50.4×37.8 mm |
| obrys | 60.73×45.07 mm |
| povrch | Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Min.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 15/20 (Typ.)(Tr/Td) |
| pozorovací uhol | 55/55/45/70 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 3S1PWLED |
| signálové rozhranie | Serial RGB (8-bit) + SPI, CCIR656, 39 pins |
| vstupné napätie | 3.3/3.3 (Typ.)(VDC/VDCI) |
| rohs: | |
| aplikácie | DSC |
