| Číslo dielu | YX035CM31 |
| Značka | |
| Veľkosť | 3.5 |
| Aplikácia | HHP |
| Rozhodnutie | 320×240 |
| Zloženie | LCM |
| Jas | 800 |
| CR | 400:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | Parallel/Serial |
| značka panelu | |
| panelový model | YX035CM31 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 320(RGB)×240 , QVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 70.08×52.56 mm |
| obrys | 76.9×63.9 mm |
| povrch | Antiglare (Haze 20%) |
| jas | 800 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 10/15 (Typ.)(Tr/Td) |
| pozorovací uhol | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 5S2PWLEDWithout Driver |
| signálové rozhranie | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| vstupné napätie | 3.3/13.9/13.6V (Typ.)(VCC/VGH/VGL) |
| aplikácie | HHP |
