| Číslo dielu | LS027B7DH01 |
| Značka | SHARP |
| Veľkosť | 2.7 |
| Aplikácia | HHP |
| Rozhodnutie | 400×240 |
| Zloženie | LCM |
| Jas | |
| CR | |
| Farby | Monochrome |
| Podsvietenie | No B/L |
| Rozhranie | SPI |
| značka panelu | SHARP |
| panelový model | LS027B7DH01 |
| typ panelu | CG-Silicon , LCM |
| veľkosť panelu | 2.7 inch |
| rozhodnutie | 400×240 , WQVGA |
| režim zobrazenia | Transflective |
| aktívna oblasť | 58.8×35.28 mm |
| obrys | 62.8×42.82 mm |
| povrch | Hard coating (3H) |
| jas | |
| kontrastný pomer | 14:1 (Typ.)(Reflective) |
| zobraziť farby | Monochrome (1-bit) |
| Doba odozvy | 10/20 (Typ.)(Tr/Td) |
| pozorovací uhol | 55/55/60/60 (Min.)(CR≥2)(L/R/U/D) |
| typ lampy | No B/L |
| signálové rozhranie | SPI, 10 pins |
| vstupné napätie | 5.0/5.0V (Typ.)(VDD/VDDA) |
| aplikácie | HHP |
