| Číslo dielu | V580DK2-LD1 |
| Značka | Innolux |
| Veľkosť | 58 |
| Aplikácia | PID |
| Rozhodnutie | 3840×2160 |
| Zloženie | LCM |
| Jas | 1000 |
| CR | 4000:1 |
| Farby | 1.07B |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | V580DK2-LD1 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 58 inch |
| rozhodnutie | 3840(RGB)×2160 , UHD |
| režim zobrazenia | Super MVA, Normally Black, Transmissive |
| aktívna oblasť | 1270.08×721.44 mm |
| obrys | 1309.5×767×60.2 mm |
| povrch | Antiglare (Haze 1%), Hard coating (3H) |
| jas | 1000 cd/m² (Typ.) |
| kontrastný pomer | 4000:1 (Typ.) |
| zobraziť farby | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Doba odozvy | 9.5 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (8 ch, 10-bit), 122 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | PID |
