| Číslo dielu | RX420-Z15 |
| Značka | ROGIN |
| Veľkosť | 42 |
| Aplikácia | PID |
| Rozhodnutie | 1920×1080 |
| Zloženie | LCM |
| Jas | 1500 |
| CR | 1200:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | ROGIN |
| panelový model | RX420-Z15 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 42 inch |
| rozhodnutie | 1920(RGB)×1080 , FHD |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 927.94×521.96 mm |
| obrys | 956.4×555 mm |
| povrch | Antiglare (Haze 1%), Hard coating (2H) |
| jas | 1500 cd/m² (Typ.) |
| kontrastný pomer | 1200:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193168% |
| Doba odozvy | 6 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (2 ch, 10-bit), 51 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | PID |
