| Číslo dielu | V260B1-L01 |
| Značka | Innolux |
| Veľkosť | 26.0 |
| Aplikácia | LCTV |
| Rozhodnutie | 1366×768 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 800:1 |
| Farby | 16.2M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | V260B1-L01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 26.0 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 575.769×323.712 mm |
| obrys | 626×373×43.2 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC), CIE193172% |
| Doba odozvy | 3/5 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 12 pcsCCFLEmbedded (Inverter) |
| signálové rozhranie | LVDS (1 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | LCTV |
| V260B1-L01 | Innolux | 26.0 | 1366×768 |
| V260B1-L02 | Innolux | 26.0 | 1366×768 |
| V260B1-L03 | Innolux | 26.0 | 1366×768 |
| V260B1-L11 | Innolux | 26.0 | 1366×768 |
| V260B2-L01 | Innolux | 26.0 | 1366×768 |
| V260B2-L04 | Innolux | 26.0 | 1366×768 |
| V260B3-L01 | Innolux | 26.0 | 1366×768 |
| V260B3-L07 | Innolux | 26.0 | 1366×768 |
| V260B3-LE1 | Innolux | 26.0 | 1366×768 |
| V260B3-LE2 | Innolux | 26.0 | 1366×768 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LC320WX6-SLA3 | LG Display | 31.5 | 1366×768 |
| LC420WUE-SDP1 | LG Display | 42 | 1920×1080 |
| LC550EUD-SCA2 | LG Display | 55 | 1920×1080 |
| LM320TU4A | PANDA | 31.5 | 1366×768 |
| LTA400HA08 | Samsung | 40 | 1920×1080 |
| LTA400HH-L02 | Samsung | 40 | 1920×1080 |
| LTA460HM02-W | Samsung | 46 | 1920×1080 |
| T260XW02 VQ | AUO | 26.0 | 1366×768 |
| T420HW07 V5 | AUO | 42 | 1920×1080 |
