| Číslo dielu | TM190MCS02 |
| Značka | Tianma |
| Veľkosť | 19.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1440×900 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | TIANMA |
| panelový model | TM190MCS02 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 19.0 inch |
| rozhodnutie | 1440(RGB)×900 , WXGA+ |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 408.24×255.15 mm |
| obrys | 428×278 mm |
| povrch | Antiglare |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193168% |
| Doba odozvy | 1.3/3.7 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
| G190EG01 V2 | AUO | 19.0 | 1280×1024 |
| HSD190MEN6-A00 | HannStar | 19.0 | 1280×1024 |
| HSD190MGW1-B00 | HannStar | 19.0 | 1440×900 |
| LM190E08-TLJ7 | LG Display | 19.0 | 1280×1024 |
| M190EG02 V9 | AUO | 19.0 | 1280×1024 |
| MT190AW02 V.0 | Innolux | 19.0 | 1440×900 |
| NL128102AC29-17 | NLT | 19.0 | 1280×1024 |
| TM190MCS02 | Tianma | 19.0 | 1440×900 |
| TM190MDS01 | Tianma | 19.0 | 1440×900 |
| TM190MFS01 | Tianma | 19.0 | 1440×900 |
| HSD190MEN3-A01 | HannStar | 19.0 | 1280×1024 |
| LM220WE1-TLK1 | LG Display | 22.0 | 1680×1050 |
| LM230WF3-SLK1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLC1 | LG Display | 23.0 | 1920×1080 |
| LM270WQ1-SDBV | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SDF1 | LG Display | 27.0 | 2560×1440 |
| M170EG01 V8 | AUO | 17.0 | 1280×1024 |
| M190A1-L01 | Innolux | 19.0 | 1440×900 |
| M240HVN02.0 | AUO | 24.0 | 1920×1080 |
| MV195WGM-N10 | BOE | 19.5 | 1440×900 |
