| Číslo dielu | LTA104A261F |
| Značka | TOSHIBA |
| Veľkosť | 10.4 |
| Aplikácia | IA |
| Rozhodnutie | 640×480 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 250:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | TTL |
| značka panelu | Toshiba Matsushita |
| panelový model | LTA104A261F 2 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.4 inch |
| rozhodnutie | 640(RGB)×480 , VGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 211.2×158.4 mm |
| obrys | 265×188.8×11.8 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 250:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 15/25 (Typ.)(Tr/Td) |
| pozorovací uhol | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhranie | CMOS (1 ch, 6-bit), 31 pins |
| vstupné napätie | 5.0V (Typ.)(VDD) |
| aplikácie | IA |
