| Číslo dielu | LQ190E1LW42 |
| Značka | SHARP |
| Veľkosť | 19.0 |
| Aplikácia | IA |
| Rozhodnutie | 1280×1024 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 900:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | SHARP |
| panelový model | LQ190E1LW42 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 19.0 inch |
| rozhodnutie | 1280(RGB)×1024 , SXGA |
| režim zobrazenia | MVA, Normally Black, Transmissive |
| aktívna oblasť | 376.32×301.056 mm |
| obrys | 404.2×330×22.5 mm |
| povrch | Antiglare (Haze 40%), Hard coating (2H) |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | 12 (Typ.)(Tr+Td); 8 (Typ.)(G to G) |
| pozorovací uhol | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 6 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | IA |
