| Číslo dielu | LQ110Y1LG12 |
| Značka | SHARP |
| Veľkosť | 11.0 |
| Aplikácia | GM |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 330 |
| CR | 500:1 |
| Farby | 16.2M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | SHARP |
| panelový model | LQ110Y1LG12 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 11.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 238.8×143.28 mm |
| obrys | 257×164.5×9.9 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 330 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC), CIE193170% |
| Doba odozvy | 23.0 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 8-bit), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | GM |
