| Číslo dielu | LQ043T1DH04 |
| Značka | SHARP |
| Veľkosť | 4.3 |
| Aplikácia | PND |
| Rozhodnutie | 480×272 |
| Zloženie | LCM |
| Jas | 360 |
| CR | 300:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | SHARP |
| panelový model | LQ043T1DH04 2 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 4.3 inch |
| rozhodnutie | 480×272(RGB) , WQVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 95.04×53.856 mm |
| obrys | 105.5×67.2×4.45 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 360 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193148% |
| Doba odozvy | 8/8 (Typ.)(Tr/Td) |
| pozorovací uhol | 45/45/20/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 9S1PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| vstupné napätie | 1.8/(3.3/2.8)V (Typ.)(VDDIO/VCI) |
| aplikácie | PND |
