| Číslo dielu | LQ043Y1DX03D |
| Značka | SHARP |
| Veľkosť | 4.3 |
| Aplikácia | MPH |
| Rozhodnutie | 480×800 |
| Zloženie | LCM |
| Jas | 340 |
| CR | 900:1 |
| Farby | 65K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | SHARP |
| panelový model | LQ043Y1DX03D |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 4.3 inch |
| rozhodnutie | 480(RGB)×800 , WVGA |
| režim zobrazenia | ASV, Normally Black, Transmissive |
| aktívna oblasť | 56.16×93.6 mm |
| obrys | 62.46×105.9 mm |
| povrch | Hard coating (3H) |
| jas | 340 cd/m² (Typ.) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 65K , CIE193172% |
| Doba odozvy | 35 (Max.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 8S1PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB, 45 pins |
| vstupné napätie | 3.3/2.6V (Typ.)(VCI/VDDIO) |
| aplikácie | MPH |
