| Číslo dielu | LTM240CS02 |
| Značka | Samsung |
| Veľkosť | 24.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1920×1200 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | RGB LED |
| Rozhranie | LVDS |
| značka panelu | SAMSUNG |
| panelový model | LTM240CS02 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 24.0 inch |
| rozhodnutie | 1920(RGB)×1200 , WUXGA |
| režim zobrazenia | S-PVA, Normally Black, Transmissive |
| aktívna oblasť | 518.4×324 mm |
| obrys | 546.4×352 mm |
| povrch | Antiglare (Haze 44%), Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE1931108% |
| Doba odozvy | 16 (Typ.)(Tr+Td); 6 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | RGB LEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| rohs: | |
| aplikácie | DMPC |
