| Číslo dielu | LA070WV4-SD01 |
| Značka | LG Display |
| Veľkosť | 7.0 |
| Aplikácia | CNS |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 470 |
| CR | 900:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | LG Display |
| panelový model | LA070WV4-SD01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 152.4×91.44 mm |
| obrys | 170×109.6 mm |
| povrch | Antiglare (Haze 11%) |
| jas | 470 cd/m² (Typ.) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193165% |
| Doba odozvy | 15/10 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 7S2PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | CNS |
