| Číslo dielu | IAQX10M |
| Značka | IDTech |
| Veľkosť | 15.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 2048×1536 |
| Zloženie | LCM |
| Jas | 200 |
| CR | 400:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | IDTech |
| panelový model | IAQX10M |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.0 inch |
| rozhodnutie | 2048(RGB)×1536 , QXGA |
| režim zobrazenia | IPS, Normally Black, Transmissive |
| aktívna oblasť | 304.1×228.1 mm |
| obrys | 326×244.5×13.3 mm |
| povrch | |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 30/30 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (2 ch, 6-bit), 30 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | DMPC |
