| Číslo dielu | HSD070PFW3-B02 |
| Značka | HannStar |
| Veľkosť | 7.0 |
| Aplikácia | MP4 |
| Rozhodnutie | 1024×600 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 800:1 |
| Farby | 16.2M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | HannStar |
| panelový model | HSD070PFW3-B02 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 1024(RGB)×600 , WSVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 153.6×90 mm |
| obrys | 165.75×105.39×3.7 mm |
| povrch | |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC), CIE193150% |
| Doba odozvy | 4/12 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/70/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 3S6PWLEDWithout Driver |
| signálové rozhranie | LVDS (1 ch, 8-bit), 40 pins |
| vstupné napätie | 3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplikácie | MP4 |
