| Číslo dielu | HR215WU1-100 |
| Značka | BOE |
| Veľkosť | 21.5 |
| Aplikácia | DMPC |
| Rozhodnutie | 1920×1080 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | BOE |
| panelový model | HR215WU1-100 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 21.5 inch |
| rozhodnutie | 1920(RGB)×1080 , FHD |
| režim zobrazenia | FFS, Normally Black, Transmissive |
| aktívna oblasť | 476.64×268.11 mm |
| obrys | 495.6×292.2×10.7 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC) |
| Doba odozvy | 14 (Typ.)(Tr+Td) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 13S4PWLEDWithout Driver |
| signálové rozhranie | LVDS (2 ch, 8-bit), 30 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
| HM215WU3-100 | BOE | 21.5 | 1920×1080 |
| HR215WU1-100 | BOE | 21.5 | 1920×1080 |
| HR215WU1-120 | BOE | 21.5 | 1920×1080 |
| HR215WU1-210 | BOE | 21.5 | 1920×1080 |
| LM215WF3-SDA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SDC2 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLE1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLE7 | LG Display | 21.5 | 1920×1080 |
| LTM215HT03 | Samsung | 21.5 | 1920×1080 |
| M215HW03 V1Q0 | AUO | 21.5 | 1920×1080 |
| LM240WU8-SLD1 | LG Display | 24.0 | 1920×1200 |
| LTM220MT09 | Samsung | 22.0 | 1680×1050 |
| LTM230HT10 | Samsung | 23.0 | 1920×1080 |
| LTM240CL04 | Samsung | 24.0 | 1920×1200 |
| M185XW01 V3 | AUO | 18.5 | 1366×768 |
| M201EW02 V6 | AUO | 20.1 | 1680×1050 |
| M220ZGE-L20 | Innolux | 22.0 | 1680×1050 |
| MT190AW02 V.4 | Innolux | 19.0 | 1440×900 |
| MT230DW01 V.0 | Innolux | 23.0 | 1920×1080 |
| QD15XL13 Rev.01 | QDI | 15.0 | 1024×768 |
