| Číslo dielu | G080Y1-T01 |
| Značka | Innolux |
| Veľkosť | 8.0 |
| Aplikácia | CNS |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 600 |
| CR | 600:1 |
| Farby | 262K/16.2M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | CMO |
| panelový model | G080Y1-T01 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 8.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 173.4×104.04 mm |
| obrys | 190×120 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 600 cd/m² (Typ.) |
| kontrastný pomer | 600:1 (Typ.) |
| zobraziť farby | 262K/16.2M (6-bit / 6-bit + FRC), CIE193172% |
| Doba odozvy | 5/11 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 9S3PWLEDWithout Driver |
| signálové rozhranie | TTL (1 ch, 6/8-bit), 60 pins |
| vstupné napätie | 3.3/12/18/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | CNS |
