| Číslo dielu | EL320.240.36 LK |
| Značka | Lumineq |
| Veľkosť | 5.7 |
| Aplikácia | IA |
| Rozhodnutie | 320×240 |
| Zloženie | EL |
| Jas | 50 |
| CR | 50:1 |
| Farby | Mono(Yellow) |
| Podsvietenie | self |
| Rozhranie | Parallel Data |
| značka panelu | Lumineq |
| panelový model | EL320.240.36 LK |
| typ panelu | EL , EL |
| veľkosť panelu | 5.7 inch |
| rozhodnutie | 320×240 , QVGA |
| aktívna oblasť | 115.1×86.3 mm |
| obrys | 148.1×104.7 mm |
| povrch | |
| jas | 50 cd/m² (Typ.) |
| kontrastný pomer | 50 : 1 (Typ.) |
| zobraziť farby | Mono(Yellow) (1-bit) |
| pozorovací uhol | 89/89/89/89 (Typ.)(L/R/U/D) |
| frekvencia | 120Hz |
| signálové rozhranie | Parallel Data (1ch, 4-bit), 20 pins |
| vstupné napätie | 5/12V (Typ.)(VL/VH) |
| aplikácie | IA |
| EL320.240-FA3 | Lumineq | 4.9 | 320×240 |
| EL320.240-FA3 CC | Lumineq | 4.9 | 320×240 |
| EL320.240.36 | Lumineq | 5.7 | 320×240 |
| EL320.240.36 AG | Lumineq | 5.7 | 320×240 |
| EL320.240.36 ET | Lumineq | 5.7 | 320×240 |
| EL320.240.36 HB NE | PLANAR | 5.7 | 320×240 |
| EL320.240.36 HB NE CC | PLANAR | 5.7 | 320×240 |
| EL320.240.36 HB SE | PLANAR | 5.7 | 320×240 |
| EL320.240.36 IN AG | Lumineq | 5.7 | 320×240 |
| EL320.240.36 LK | Lumineq | 5.7 | 320×240 |
| EG4401S-ER | Epson | 5.3 | 256×128 |
| G121SN01 V3 | AUO | 12.1 | 800×600 |
| G190SF01 V0 | AUO | 19.0 | 1680×342 |
| LM-CK53-22NFR | SANYO | 9.4 | 640×480 |
| LM100SS1T522 | SHARP | 10.0 | 800×600 |
| LQ070Y3LG4A | SHARP | 7.0 | 800×480 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| LTM04C380K | TOSHIBA | 4.0 | 640×480 |
| NL8060BC21-03 | NLT | 8.4 | 800×600 |
| OEL9M0073-B-E | Other | 1.0 | 128×64 |
