| Číslo dielu | EL160.80.50 |
| Značka | Lumineq |
| Veľkosť | 3.5 |
| Aplikácia | IA |
| Rozhodnutie | 160×80 |
| Zloženie | EL |
| Jas | 80 |
| CR | 50:1 |
| Farby | Mono(Yellow) |
| Podsvietenie | self |
| Rozhranie | Parallel Data |
| značka panelu | Lumineq |
| panelový model | EL160.80.50 |
| typ panelu | EL , EL |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 160×80 |
| aktívna oblasť | 79.9×39.9 mm |
| obrys | 108.9×57.2 mm |
| povrch | |
| jas | 80 cd/m² (Typ.) |
| kontrastný pomer | 50 : 1 (Typ.) |
| zobraziť farby | Mono(Yellow) (1-bit) |
| pozorovací uhol | 89/89/89/89 (Typ.)(L/R/U/D) |
| frekvencia | 240Hz |
| signálové rozhranie | Parallel Data (1ch, 4-bit), 20 pins |
| vstupné napätie | 5/12V (Typ.)(VL/VH) |
| aplikácie | IA |
| EL160.120.39 | Lumineq | 3.1 | 160×120 |
| EL160.120.39 CC | Lumineq | 3.1 | 160×120 |
| EL160.80.50 | Lumineq | 3.5 | 160×80 |
| EL160.80.50 ALU | PLANAR | 3.5 | 160×80 |
| EL160.80.50 ET | Lumineq | 3.5 | 160×80 |
| EL160.80.50 ET CC | Lumineq | 3.5 | 160×80 |
| EL160.80.50 IN | Lumineq | 3.5 | 160×80 |
| EL160.80.50 IN LC CC | Lumineq | 3.5 | 160×80 |
| EL160.80.50 LC CC | Lumineq | 3.5 | 160×80 |
| PW035XU1 | E Ink | 3.5 | 320×234 |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| AC150XA02 | Mitsubishi | 15.0 | 1024×768 |
| AT056TN52 V.2 | Innolux | 5.6 | 640×480 |
| BA104S01-100 | BOE | 10.4 | 800×600 |
| G084SN02 V0 | AUO | 8.4 | 800×600 |
| LQ075V3DG01 | SHARP | 7.5 | 640×480 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL8060BC26-30C | NLT | 10.4 | 800×600 |
| NLB150XG01L-01 | NLT | 15.0 | 1024×768 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
