| Číslo dielu | CLAA090NA02CW |
| Značka | CPT |
| Veľkosť | 9.0 |
| Aplikácia | NOPC |
| Rozhodnutie | 1024×600 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 500:1 |
| Farby | 262K/16.2M |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | CPT |
| panelový model | CLAA090NA02CW |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 9.0 inch |
| rozhodnutie | 1024(RGB)×600 , WSVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 196.608×114.15 mm |
| obrys | 211.1×126.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 500:1 (Typ.) |
| zobraziť farby | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 4S6PWLEDWithout Driver |
| signálové rozhranie | LVDS (1 ch, 8-bit), 60 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NOPC |
| AT102TN42 | Innolux | 10.2 | 1024×600 |
| B101AW01 V2 HW5A | AUO | 10.1 | 1024×576 |
| B101AW06 V4 | AUO | 10.1 | 1024×600 |
| B116XW02 V1 | AUO | 11.6 | 1366×768 |
| BA101WS1-100 | BOE | 10.1 | 1024×600 |
| BT101IW04 V.0 | Innolux | 10.1 | 1024×600 |
| LP116WH1-TLA1 | LG Display | 11.6 | 1366×768 |
| M101NWT2 R1 | IVO | 10.1 | 1024×600 |
| N101LGE-L41 | Innolux | 10.1 | 1024×600 |
| N116BGE-EA2 | Innolux | 11.6 | 1366×768 |
