| Číslo dielu | LP116WH1-TLA1 |
| Značka | LG Display |
| Veľkosť | 11.6 |
| Aplikácia | NOPC |
| Rozhodnutie | 1366×768 |
| Zloženie | LCM |
| Jas | 200 |
| CR | 300:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | LG Display |
| panelový model | LP116WH1-TLA1 7 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 11.6 inch |
| rozhodnutie | 1366(RGB)×768 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 256.125×144 mm |
| obrys | 268×161.5×5.2 mm |
| tvarový štýl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Glare (Haze 0%) |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Min.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 9 (Typ.)(Tr+Td) |
| pozorovací uhol | 30/30/10/20 (Min.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NOPC |
