| Číslo dielu | CLAA070LF06CW |
| Značka | CPT |
| Veľkosť | 7.0 |
| Aplikácia | CNS |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 500 |
| CR | 400:1 |
| Farby | 16.2M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | CPT |
| panelový model | CLAA070LF06CW |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 154.08×85.92 mm |
| obrys | 164.9×100×4.52 mm |
| povrch | Antiglare |
| jas | 500 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 16.2M (6-bit + FRC), CIE193150% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 9S3PWLEDWithout Driver |
| signálové rozhranie | TTL (1 ch, 8-bit), 67 pins |
| vstupné napätie | 3.3/9.6/18.0/-6 (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikácie | CNS |
