| Číslo dielu | CLAA057VC01CT |
| Značka | CPT |
| Veľkosť | 5.7 |
| Aplikácia | IA |
| Rozhodnutie | 640×480 |
| Zloženie | LCM |
| Jas | 180 |
| CR | 300:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | CPT |
| panelový model | CLAA057VC01CT |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 5.7 inch |
| rozhodnutie | 640(RGB)×480 , VGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 116.16×87.12 mm |
| obrys | 127×100×8.15 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 180 cd/m² (Typ.) |
| kontrastný pomer | 300:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193150% |
| Doba odozvy | 30 (Typ.)(Tr+Td) |
| pozorovací uhol | 70/70/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | TTL (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| CLAA050JA01CT | CPT | 5.0 | 480×272 |
| CLAA050LA0ACW | CPT | 5.0 | 800×480 |
| CLAA057VA01CW | CPT | 5.7 | 640×480 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| CLAA057VC01CT | CPT | 5.7 | 640×480 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| EL320.240.36 IN AG | Lumineq | 5.7 | 320×240 |
| LM057QB1T073 | SHARP | 5.7 | 320×240 |
| TM057QVHG01 | Tianma | 5.7 | 640×480 |
| ACM019A | Other | 2.4 | 128×64 |
| DMF-50773NF-FW | Kyocera | 5.4 | 240×128 |
| DMF5003NF-FW | Kyocera | 4.7 | 160×128 |
| LM-EH53-22NTK | SANYO | 10.4 | 640×480 |
| LQ104V1DC41 | SHARP | 10.4 | 640×480 |
| LTA150XH-L06 | Samsung | 15.0 | 1024×768 |
| LTM121SI-T01 | Samsung | 12.1 | 800×600 |
| NL8060BC21-03 | NLT | 8.4 | 800×600 |
| NL8060BC31-41D | NLT | 12.1 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
