| Číslo dielu | B154SW01 V2 |
| Značka | AUO |
| Veľkosť | 15.4 |
| Aplikácia | NBPC |
| Rozhodnutie | 1680×1050 |
| Zloženie | LCM |
| Jas | 200 |
| CR | 400:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | B154SW01 V2 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 15.4 inch |
| rozhodnutie | 1680(RGB)×1050 , WSXGA+ |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 331.38×207.11 mm |
| povrch | Glare (Haze 0%) |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 262K (6-bit) |
| Doba odozvy | 16 (Typ.)(Tr+Td) |
| pozorovací uhol | 60/60/45/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFL |
| signálové rozhranie | LVDS (2 ch, 6-bit), 30 pins |
| aplikácie | NBPC |
