| Číslo dielu | N121IB-L06 |
| Značka | Innolux |
| Veľkosť | 12.1 |
| Aplikácia | NBPC |
| Rozhodnutie | 1280×800 |
| Zloženie | LCM |
| Jas | 220 |
| CR | 600:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | N121IB-L06 5 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 12.1 inch |
| rozhodnutie | 1280(RGB)×800 , WXGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 261.12×163.2 mm |
| obrys | 275.8×178×5.3 mm |
| tvarový štýl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 220 cd/m² (Typ.) |
| kontrastný pomer | 600:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193140% |
| Doba odozvy | 3/7 (Typ.)(Tr/Td) |
| pozorovací uhol | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 7S6PWLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
| N121I2-L01 | Innolux | 12.1 | 1280×800 |
| N121I3-L01 | Innolux | 12.1 | 1280×800 |
| N121I3-L03 | Innolux | 12.1 | 1280×800 |
| N121I6-L01 | Innolux | 12.1 | 1280×800 |
| N121I7-L01 | Innolux | 12.1 | 1280×800 |
| N121IA-L02 | Innolux | 12.1 | 1280×800 |
| N121IB-L04 | Innolux | 12.1 | 1280×800 |
| N121IB-L05 Rev.C1 | Innolux | 12.1 | 1280×800 |
| N121IB-L06 | Innolux | 12.1 | 1280×800 |
| NL8060BC31-02 | NLT | 12.1 | 800×600 |
| B156XW02 V2 HW4A | AUO | 15.6 | 1366×768 |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| LP133WH2-TLL3 | LG Display | 13.3 | 1366×768 |
| LP156WF4-SPH3 | LG Display | 15.6 | 1920×1080 |
| LP156WH3-TLE1 | LG Display | 15.6 | 1366×768 |
| LTD121KX5V | TOSHIBA | 12.1 | 1280×800 |
| LTN141XB-L04 | Samsung | 14.1 | 1024×768 |
| LTN173KT03-B01 | Samsung | 17.3 | 1600×900 |
| N121IA-L02 | Innolux | 12.1 | 1280×800 |
| N140BGE-EA3 | Innolux | 14.0 | 1366×768 |
