| Číslo dielu | B101AW06 V1 HW1A |
| Značka | AUO |
| Veľkosť | 10.1 |
| Aplikácia | NOPC |
| Rozhodnutie | 1024×600 |
| Zloženie | LCM |
| Jas | 200 |
| CR | 400:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | B101AW06 V1 HW1A |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 10.1 inch |
| rozhodnutie | 1024(RGB)×600 , WSVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 222.72×125.28 mm |
| obrys | 245×146.5×3.6 mm |
| tvarový štýl | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| povrch | Glare (Haze 0%), Hard coating (3H), Reflection 4.3% (Typ.) |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193145% |
| Doba odozvy | 9/7 (Typ.)(Tr/Td) |
| pozorovací uhol | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 40 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NOPC |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| B101AW01 V2 HW0A | AUO | 10.1 | 1024×576 |
| B101AW06 V1 HW0A | AUO | 10.1 | 1024×600 |
| B101AW06 V1 HW1A | AUO | 10.1 | 1024×600 |
| B101AW06 V4 | AUO | 10.1 | 1024×600 |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| HSD101PFW4-A00 | HannStar | 10.1 | 1024×600 |
| LD101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| M101NWT2 R0 | IVO | 10.1 | 1024×600 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
| B089AW01 V2 | AUO | 8.9 | 1024×600 |
| B101AW01 V2 HW0A | AUO | 10.1 | 1024×576 |
| B101AW01 V2 HW5A | AUO | 10.1 | 1024×576 |
| B101AW06 V4 | AUO | 10.1 | 1024×600 |
| LTN116AT01-A01 | Samsung | 11.6 | 1366×768 |
| LTN116AT02-D01 | Samsung | 11.6 | 1366×768 |
| N089L6-L02 | Innolux | 8.9 | 1024×600 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
| N116B6-L02 | Innolux | 11.6 | 1366×768 |
| N116BGE-L42 | Innolux | 11.6 | 1366×768 |
