| Číslo dielu | AM-1024600K5TMQW-01H |
| Značka | AMPIRE |
| Veľkosť | 7.0 |
| Aplikácia | Industrial Outdoor H |
| Rozhodnutie | 1024×600 |
| Zloženie | LCM , a-Si TFT-LCD |
| Jas | |
| CR | 700:1 |
| Farby | 16.7M |
| Podsvietenie | 8S3P |
| Rozhranie | LVDS |
| výrobca | AMPIRE |
| veľkosť obrazovky | 7.0 inch |
| počet pixelov | 1024(RGB)×600 (WSVGA) 169PPI |
| aktívna plocha (mm) | 153.6 × 90 (H×V) |
| plocha rámu (mm) | 156.2 × 92.6 (H×V) |
| jas | 1000 cd/m² (Typ.) |
| pozorovací uhol | 75/75/70/75 (Typ.)(CR≥10) |
| dobrý výhľad na | - |
| farebná hĺbka | 16.7M |
| omša | TBD |
| obnovovacia frekvencia | 60Hz |
| typ signálu | LVDS (1 ch, 8-bit) , 20 pins Connector |
| napájací zdroj | 3.3V (Typ.) |
| max. hodnotenia | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| meno modela | AM-1024600K5TMQW-01H |
| typ obrazovky | LCM , a-Si TFT-LCD |
| usporiadanie | RGB Vertical Stripe |
| obrys (mm) | 165.5 × 104.44 × 9.46 (H×V×D) |
| liečbe | Glare (Haze 0%), Hard coating |
| kontrastný pomer | 700 : 1 (Typ.) (TM) |
| odpoveď | 20/20 (Typ.)(Tr/Td) ms |
| pracovný režim | TN, Normally White, Transmissive |
| podsvietenie | 8S3P WLED , 50K hours , With LED Driver |
| používa | Industrial Outdoor High Brightness |
| dotyková obrazovka | Without |
