| Číslo dielu | A070VW04 V0 |
| Značka | AUO |
| Veľkosť | 7.0 |
| Aplikácia | MP4 |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 200 |
| CR | 400:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | AUO |
| panelový model | A070VW04 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 7.0 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 152.4×91.44 mm |
| obrys | 164×103×5.4 mm |
| povrch | Antiglare |
| jas | 200 cd/m² (Typ.) |
| kontrastný pomer | 400:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 12/18 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 3S7PWLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| vstupné napätie | 3.3/11/18/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikácie | MP4 |
