| Číslo dielu | A035VL01 V3 |
| Značka | AUO |
| Veľkosť | 3.5 |
| Aplikácia | DVC |
| Rozhodnutie | 800×480 |
| Zloženie | LCM |
| Jas | 315 |
| CR | 800:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | TTL |
| značka panelu | AUO |
| panelový model | A035VL01 V3 |
| typ panelu | LTPS TFT-LCD , LCM |
| veľkosť panelu | 3.5 inch |
| rozhodnutie | 800(RGB)×480 , WVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 75.6×45.36 mm |
| obrys | 86.1×51.66 mm |
| povrch | Glare (Haze 0%) |
| jas | 315 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit) |
| Doba odozvy | 15/30 (Typ.)(Tr/Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| vstupné napätie | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| aplikácie | DVC |
| A035VL01 V0 | AUO | 3.5 | 800×480 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| A035VL01 V6 | AUO | 3.5 | 800×480 |
| CT035TN02 | Innolux | 3.5 | 320×480 |
| ET035009DH6 | EDT | 3.5 | 320×240 |
| GPM782A0 | Giantplus | 3.5 | 320×240 |
| LQ035Q7DH02 | SHARP | 3.5 | 240×320 |
| NL2432HC22-25E | NLT | 3.5 | 240×320 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| UMSH-8065MD-11T | Other | 3.5 | 320×240 |
| 990000553 | TPO | 3.5 | 320×240 |
| A035CN02 V1 | AUO | 3.5 | 480×234 |
| A035VL01 V0 | AUO | 3.5 | 800×480 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| COM48T4Mxxxxx | ORTUSTECH | 4.8 | 1920×1080 |
| LS032V8DY01 | SHARP | 3.2 | 640×480 |
| LTV280QV-F02 | Samsung | 2.8 | 320×240 |
| PD035QX2 | E Ink | 3.5 | 320×240 |
| PW035XU1 | E Ink | 3.5 | 320×234 |
