| Číslo dielu | V460H1-L09 |
| Značka | Innolux |
| Veľkosť | 46 |
| Aplikácia | LCTV |
| Rozhodnutie | 1920×1080 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 6000:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | V460H1-L09 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 46 inch |
| rozhodnutie | 1920(RGB)×1080 , FHD |
| režim zobrazenia | Super MVA, Normally Black, Transmissive |
| aktívna oblasť | 1018.08×572.67 mm |
| obrys | 1083×627 mm |
| povrch | Antiglare (Haze 11%), Hard coating (3H) |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 6000:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193172% |
| Doba odozvy | 6.5 (Typ.)(G to G) |
| pozorovací uhol | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 14 pcsCCFLEmbedded (Inverter) |
| signálové rozhranie | LVDS (2 ch, 8-bit), 51 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | LCTV |
