| Číslo dielu | TX38D25VM0CAA |
| Značka | KOE |
| Veľkosť | 14.9 |
| Aplikácia | IA |
| Rozhodnutie | 1280×242 |
| Zloženie | LCM |
| Jas | 450 |
| CR | 800:1 |
| Farby | 262K |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | KOE |
| panelový model | TX38D25VM0CAA |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 14.9 inch |
| rozhodnutie | 1280(RGB)×242 |
| režim zobrazenia | IPS NP, Normally Black, Transmissive |
| aktívna oblasť | 372.48×70.42 mm |
| obrys | 386.82×85.57 mm |
| povrch | |
| jas | 450 cd/m² (Typ.) |
| kontrastný pomer | 800:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193160% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (1 ch, 6-bit), 20 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | IA |
