| Číslo dielu | TV122WXM-NW0 |
| Značka | BOE |
| Veľkosť | 12.2 |
| Aplikácia | NBPC |
| Rozhodnutie | 1280×800 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 900:1 |
| Farby | 16.7M |
| Podsvietenie | WLED |
| Rozhranie | eDP |
| značka panelu | BOE |
| panelový model | TV122WXM-NW0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 12.2 inch |
| rozhodnutie | 1280(RGB)×800 , WXGA |
| režim zobrazenia | ADS, Normally Black, Transmissive |
| aktívna oblasť | 262.565×164.16 mm |
| obrys | 271.06×176.42×2.86 mm |
| povrch | |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 900:1 (Typ.) |
| zobraziť farby | 16.7M (8-bit), CIE193150% |
| Doba odozvy | 30 (Typ.)(Tr+Td) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhranie | eDP (2 Lanes), 39 pins |
| vstupné napätie | 3.3V (Typ.) |
| aplikácie | NBPC |
