| Číslo dielu | TM022GBH01 |
| Značka | Tianma |
| Veľkosť | 2.2 |
| Aplikácia | MPH |
| Rozhodnutie | 176×220 |
| Zloženie | LCM |
| Jas | 250 |
| CR | 350:1 |
| Farby | 65K/262K |
| Podsvietenie | WLED |
| Rozhranie | CPU |
| značka panelu | TIANMA |
| panelový model | TM022GBH01 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 2.2 inch |
| rozhodnutie | 176(RGB)×220 , QCIF+ |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 34.848×43.56 mm |
| obrys | 41.7×56.16 mm |
| povrch | Clear, Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastný pomer | 350:1 (Typ.) |
| zobraziť farby | 65K/262K , CIE193160% |
| Doba odozvy | 25 (Typ.)(Tr+Td) |
| pozorovací uhol | 45/45/40/20 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 1S3PWLEDWithout Driver |
| signálové rozhranie | CPU, 36 pins |
| vstupné napätie | 2.8V (Typ.)(VDD) |
| aplikácie | MPH |
