| Číslo dielu | T546HB01 V0 |
| Značka | AUO |
| Veľkosť | 55 |
| Aplikácia | LCTV |
| Rozhodnutie | 1920×1080 |
| Zloženie | LCM |
| Jas | 360 |
| CR | 4000:1 |
| Farby | 16.7M/1.07B |
| Podsvietenie | WLED |
| Rozhranie | LVDS |
| značka panelu | AUO |
| panelový model | T546HB01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 55 inch |
| rozhodnutie | 1920(RGB)×1080 , FHD |
| režim zobrazenia | AMVA3, Normally Black, Transmissive |
| aktívna oblasť | 1209.6×680.4 mm |
| obrys | 1255.6×726.4 mm |
| povrch | |
| jas | 360 cd/m² (Typ.) |
| kontrastný pomer | 4000:1 (Typ.) |
| zobraziť farby | 16.7M/1.07B (8-bit / 8-bit + Hi-FRC), CIE193172% |
| Doba odozvy | 5.5 (Typ.)(G to G) |
| pozorovací uhol | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 120Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhranie | LVDS (4 ch, 8/10-bit), 92 pins |
| vstupné napätie | 12.0V (Typ.) |
| aplikácie | LCTV |
