| Číslo dielu | NL8060BC31-27D |
| Značka | NLT |
| Veľkosť | 12.1 |
| Aplikácia | IA |
| Rozhodnutie | 800×600 |
| Zloženie | LCM |
| Jas | 400 |
| CR | 600:1 |
| Farby | 262K |
| Podsvietenie | CCFL |
| Rozhranie | TTL |
| značka panelu | NEC |
| panelový model | NL8060BC31-27D |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 12.1 inch |
| rozhodnutie | 800(RGB)×600 , SVGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 246×184.5 mm |
| obrys | 280×210×13.7 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastný pomer | 600:1 (Typ.) |
| zobraziť farby | 262K (6-bit), CIE193140% |
| Doba odozvy | 8/25 (Typ.)(Tr/Td) |
| pozorovací uhol | 70/70/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhranie | CMOS (1 ch, 6-bit), 41 pins |
| vstupné napätie | 3.3/5.0V (Typ.) |
| rohs: | |
| aplikácie | IA |
| NL8060BC21-02 | NLT | 8.4 | 800×600 |
| NL8060BC26-15 | NLT | 10.4 | 800×600 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
| NL8060BC26-28 | NLT | 10.4 | 800×600 |
| NL8060BC26-30D | NLT | 10.4 | 800×600 |
| NL8060BC31-27 | NLT | 12.1 | 800×600 |
| NL8060BC31-27D | NLT | 12.1 | 800×600 |
| NL8060BC31-28D | NLT | 12.1 | 800×600 |
| NL8060BC31-41E | NLT | 12.1 | 800×600 |
| NL8060BC31-47 | NLT | 12.1 | 800×600 |
| COM50H5125XLC | ORTUSTECH | 5.0 | 320×240 |
| G150XG03 V0 | AUO | 15.0 | 1024×768 |
| HSD190MEN6-A01 | HannStar | 19.0 | 1280×1024 |
| LB104V03-A1 | LG Display | 10.4 | 640×480 |
| LM10V332 | SHARP | 10.4 | 640×480 |
| LQ104S1DG21 | SHARP | 10.4 | 800×600 |
| LT065AB3D600 | TOSHIBA | 6.5 | |
| NL10276BC20-37 | NLT | 10.4 | 1024×768 |
| NL6448BC33-59D | NLT | 10.4 | 640×480 |
| PD050OX1 | E Ink | 5.0 | 480×480 |
