| Číslo dielu | NL6448AC30-10 |
| Značka | NLT |
| Veľkosť | 9.4 |
| Aplikácia | IA |
| Rozhodnutie | 640×480 |
| Zloženie | LCM |
| Jas | 90 |
| CR | 110:1 |
| Farby | 4096 |
| Podsvietenie | CCFL |
| Rozhranie | TTL |
| značka panelu | NEC |
| panelový model | NL6448AC30-10 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 9.4 inch |
| rozhodnutie | 640(RGB)×480 , VGA |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 192×144 mm |
| obrys | 259.5×179×12.5 mm |
| povrch | |
| jas | 90 cd/m² (Typ.) |
| kontrastný pomer | 110:1 (Typ.) |
| zobraziť farby | 4096 (4-bit), CIE193155% |
| Doba odozvy | 40 (Max.)(Tr+Td) |
| pozorovací uhol | 45/45/25/25 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 60Hz |
| typ lampy | 1 pcsCCFLEmbedded (Inverter) |
| signálové rozhranie | CMOS (1 ch, 4-bit), 34 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | IA |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| NL6448BC18-01F | NLT | 5.7 | 640×480 |
| NL6448BC20-30F | NLT | 6.5 | 640×480 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| NL6448BC33-59D | NLT | 10.4 | 640×480 |
| NL6448BC33-64 | NLT | 10.4 | 640×480 |
| B084SN02 V0 | AUO | 8.4 | 800×600 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| G101AGE-L01 | Innolux | 10.1 | 800×600 |
| LM24014H | SHARP | 5.2 | 240×64 |
| LMG5278XUFC-A | KOE | 9.4 | 640×480 |
| LP064V1 | LG Display | 6.4 | 640×480 |
| LQ121S1DC71 | SHARP | 12.1 | 800×600 |
| SP14N002 | KOE | 5.1 | 240×128 |
| TM121SV-A01 | SANYO | 12.1 | 800×600 |
| TM320240EGFWVSWD | Tianma | 5.7 | 320×240 |
