| Číslo dielu | NL12880BC20-25F |
| Značka | NLT |
| Veľkosť | 12.1 |
| Aplikácia | Industrial Outdoor H |
| Rozhodnutie | 1280×800 |
| Zloženie | LCM, a-Si TFT-LCD |
| Jas | |
| CR | 800:1 |
| Farby | 262K/16.7M |
| Podsvietenie | 3 |
| Rozhranie | LVDS |
| výrobca | NLT |
| meno modela | NL12880BC20-25F |
| veľkosť obrazovky | 12.1 inch |
| typ obrazovky | LCM, a-Si TFT-LCD |
| počet pixelov | 1280(RGB)×800 (WXGA) 124PPI |
| usporiadanie | RGB Vertical Stripe |
| aktívna plocha (mm) | 261.12 × 163.2 (H×V) |
| obrys (mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| plocha rámu (mm) | 266.1 × 168.2 (H×V) |
| liečbe | Antiglare, Hard coating (3H) |
| jas | 1600 cd/m² (Typ.) |
| kontrastný pomer | 800 : 1 (Typ.) (TM) |
| pozorovací uhol | 80/80/80/80 (Typ.)(CR≥10) |
| odpoveď | 15 (Typ.)(Tr+Td) ms |
| dobrý výhľad na | 6 o'clock |
| pracovný režim | TN, Normally White, Transmissive |
| farebná hĺbka | 262K/16.7M 50% NTSC |
| podsvietenie | 3 strings WLED , 60K hours , No Driver |
| omša | 470g (Typ.) |
| používa | Industrial Outdoor High Brightness |
| obnovovacia frekvencia | 60Hz |
| dotyková obrazovka | Without |
| typ signálu | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| napájací zdroj | 3.3V (Typ.) |
| max. hodnotenia | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
