| Číslo dielu | M220Z1-L09 |
| Značka | Innolux |
| Veľkosť | 22.0 |
| Aplikácia | DMPC |
| Rozhodnutie | 1680×1050 |
| Zloženie | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Farby | 16.7M |
| Podsvietenie | CCFL |
| Rozhranie | LVDS |
| značka panelu | CMO |
| panelový model | M220Z1-L09 |
| typ panelu | a-Si TFT-LCD , LCM |
| veľkosť panelu | 22.0 inch |
| rozhodnutie | 1680(RGB)×1050 , WSXGA+ |
| režim zobrazenia | TN, Normally White, Transmissive |
| aktívna oblasť | 473.76×296.1 mm |
| obrys | 493.7×320.1 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastný pomer | 1000:1 (Typ.) |
| zobraziť farby | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odozvy | 1.3/3.7 (Typ.)(Tr/Td) |
| pozorovací uhol | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencia | 120Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhranie | LVDS (4 ch, 8-bit), 66 pins |
| vstupné napätie | 5.0V (Typ.) |
| aplikácie | DMPC |
| LM220WE5-TLA1 | LG Display | 22.0 | 1680×1050 |
| LTM220MT09 | Samsung | 22.0 | 1680×1050 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L03 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L05 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L09 | Innolux | 22.0 | 1680×1050 |
| M220Z1-L0A | Innolux | 22.0 | 1680×1050 |
| M220Z1-P03 | Innolux | 22.0 | 1680×1050 |
| M220Z3-LA3 | Innolux | 22.0 | 1680×1050 |
| M220ZGE-L20 | Innolux | 22.0 | 1680×1050 |
| HSD190ME13-D10 | HannStar | 19.0 | 1280×1024 |
| HT190WG1-600 | BOE | 19.0 | 1440×900 |
| LM201U04-A3K6 | LG Display | 20.1 | 1600×1200 |
| LM230WF5-TLD5 | LG Display | 23.0 | 1920×1080 |
| LTM170E4-P01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L01 | Samsung | 17.0 | 1280×1024 |
| M190A1-L0A | Innolux | 19.0 | 1440×900 |
| M215HW01 VB | AUO | 21.5 | 1920×1080 |
| M236H3-LA3 | Innolux | 23.6 | 1920×1080 |
| MT190AW01 V.C | Innolux | 19.0 | 1440×900 |
